Fishmouth Pipe Template Measures - Paperback
$40.43
Skip to product information
Fishmouth Pipe Template Measures - Paperback
$40.43
by James a. Fucciani (Author)
Table of Contents: Standard Wall Pipe Data with ordinate spacing Decimal Equivalents of Fractions of an Inch 90 Intersections LATERALS Template Layout 22 1/2 Laterals 30 Laterals 45 Laterals 60 Laterals Concentric Branch on Back of a 90 Elbow Eccentric Branch on Back of a 90 Elbow 90 Eccentric Pipe Riser 5 to 45 Angle of Cut FABRICATED ELBOWS Template Layout 3-Piece 4-Piece 5-Piece 6-Piece FULL-SIZE WYES Template Layout 22 1/2 Wye 30 Wye 45 Wye 60 Wye MITER CUTS 1" through 42" 5 , 10 , 11 1/4 ,12 1/2 , 15 , 20 , 22 1/2 , 25 , 30 , 35 , 40 ,45 , 50 , 55 , 60 , 65 , 70 , 75 , 80 , 85
Number of Pages: 264
Dimensions: 0.55 x 7.8 x 5.08 IN
Publication Date: July 08, 2016
